Chapter 2. hardware setup, Hardware setup – MSI G52-MA00628 User Manual
Page 16
Hardware Setup
2-1
Chapter 2. Hardware Setup
TOPICS
Central Processing Unit: CPU
2-2
Memory
2-5
Power Supply
2-7
Back Panel
2-8
Connectors
2-13
Jumpers
2-25
Slots
2-26
2
Hardware Setup
This chapter provides you with the information about hardware setup
procedures. While doing the installation, be careful in holding the components
and follow the installation procedures. For some components, if you install in
the wrong orientation, the components will not work properly.
Use a grounded wrist strap before handling computer components. Static
electricity may damage the components.
