Chapter 2
2-6
Install at least one DIMM module on the slot. Memory modules can be
installed on the slots in any order. You can install either single- or double-sided
modules to meet your own needs.
Memory modules can be installed in any combination as follows:
DDR Module Combination
Installing DDR Modules
1. The DDR DIMM has only one notch on the center of module. The module
will only fit in the right orientation.
2. Insert the DIMM memory module vertically into the DIMM slot. Then
push it in until the golden finger on the memory module is deeply inserted
in the socket.
3. The plastic clip at each side of the DIMM slot will automatically close.
TIP: You can barely see the golden finger if the module is properly
inserted in the socket.
Volt
notch
S: Single Side D: Double Side
Slot Memory Module Total Memory
DIMM 2
(Bank 2 & 3)
S/D 64MB~1GB
Maximum System Memory Supported 64MB~2GB
DIMM 1
(Bank 0 & 1)
S/D 64MB~1GB
