MSI G52-MA00628 User Manual
Page 36
Hardware Setup
2-21
IEEE 1394 Connectors: J1394_1 and J1394_2 (optional)
The mainboard provides two 1394 pin headers that allow you to connect
optional IEEE 1394 ports.
J1394_1
1
TPA+
6 TPB-
2
TPA-
7 +12V (Fused)
3
Ground 8 +12V (Fused)
4
Ground 9 Key (no pin)
5
TPB+
10 Ground
Pin Signal Pin Signal
J1394_2
2
10
1
9
2
10
1
9
