Modem connector: jmod – MSI G52-MA00628 User Manual
Page 38
Hardware Setup
2-23
Modem Connector: JMOD
This connector is connected to a MSI proprietary modem module MS-
6961. This modem module functions in the same way as a modem, which allows
users to connect to the internet via the telephone line.
MSI Modem Module
MS-6961
Connect to a telephone set
Connect to a telephone line from the wall
JMOD
2
1
12
11
