5-50 Maintenance and inspection procedures
5Maintenance and Inspection
Table 5-5 ： Lubrication specifications
The grease nipple position is shown in Fig. 5-6 . The lubrication specifications for each place are shown in Fig. 5-6
［Caution］
・ The brands of grease given in
Table 5-5 are those filled when the robot is shipped.
・ The lubrication time is a cumulative value of the operation at the maximum speed. If the operation has been
suspended, or if the designated speed is slow, the lubrication time can be lengthened in proportion.
(The "Lubrication interval " in
Table 5-5 is usually based on the three-year inspection. 8Hr x 20 days x 36
months = 6000Hr.）
・ Depending on the robot operation state, the lubrication time will fluctuate, so determine the time according to
the state so that the grease does not run out.
・ With the maintenance forecast function of the personal computer support software (option), the guidance of
lubrication time is calculated according to the operating environment of the customer.
・ The numbers in the correspond to the supply positions in Fig. 5-6 .
・Avoid excessive lubrication since it may lead to grease leak. Also, the number of lubrications is limited to 3 times.
(2) Lubrication method
1) Set the robot to the posture shown in Fig. 5-6 .
2) Refer to the "5.3.2Installing/removing the cover" on page 44 and remove the covers.
3) Remove the drain bolt or plug.
4) Insert the grease shown in
Table 5-5 using a grease gun from the lubrication grease nipple.
5) Install the drain bolt or plug.
6) Replace the covers with the removal procedure in reverse.
No. Parts to be lubricated
Oiling
method
Lubrication oil
(maker)
Default charge
amount
Lubrication
interval
Lubrication
amount
Cover to remove
1 J1 axis reduction gears
Grease
nipple
WA-610
Grease
Harmonic grease SK-1A
（Japan Harmonic
Systems）
60g
6000Hr
14g Shoulder cover B
2 J2 axis reduction gears 60g 14g No.1 arm cover
3 J3 axis reduction gears 40g 8g No.1 arm cover
4 J4 axis reduction gears Grease
nipple
WB-610 16g 4g
5 J5 axis reduction gears 10g 2g Wrist cover
6 J6 axis reduction gears 10g 2g Wrist cover
