2Unpacking to Installation
Confirming the product 2-5
2 Unpacking to Installation
2.1 Confirming the product
The standard configuration of the robot arm, part of the purchased product, is shown in Table 2-1 .
Confirm the parts.
Users who have purchased optional products should refer to the separate "Standard Specifications".
Table 2-1 ： Standard configuration
No. Part name Type Qty. Remarks
1 Robot arm RV-6S series 1 unit
2 Guarantee card 1 copy
3 Installation bolts M8x40 4 pcs.
4 Spring washer for installation bolts For M8 4 pcs.
5 Plain washer for installation bolts For M8 4 pcs.
6 Suspension fitting 2 pcs.
This is installed in the robot arm
at the time of shipment.
7 Suspension fitting installation bolt 1 set
8 Fixing plates 1 pcs.
9 Fixing plate installation bolt 1 set
