Monessen Hearth HVFL18 - Manual (Page 15)

59D1015 15
Heater in
Fireplace or
Firebox
Heat
Resistant
Material
10"
8"
6"
2
1 /
2
"
8" 14" 20 1 /
2
" 24 5 /
8
" 28"
Heater in
Fireplace or
Firebox
Heat
Resistant
Material
Hood
10"
12"
8"
6"
2 1 /
2
"
8" 14 1 /
2
" 18 5 /
8
" 22 1 /
2
" 26"
CLEARANCES
AND
HEIGHT REQUIRMENTS
Figure 8 - Minimum Mantel Clearance with Hood - All Models
Example: A mantel may project from the wall a maximum of 2 1 /
2
" at a
minimum of 14" above the opening, and a maximum of 6" at a mini-
mum of 20 1 /
2
" above the opening.
Example: A mantel may project from the wall a maximum of 2 1 /
2
" at a
minimum of 8" above the opening, and a maximum of 6" at a mini-
mum of 14 1 /
2
" above the opening.
Figure 7 - Minimum Mantel Clearance with No Hood - HVFL18
