Memorex MLT1522 - Manual (Page 26)

Main Menu
Main Disp
Image Setup
Audio Setup
PC Setup
TV Setup
Language
Recall
Quit
Image Setup
Brightness
Contrast
Sharpness
Tint
Color
Return
Audio Setup
Treble
Bass
Balance
Return
PC Setup
Treble
Bass
Balance
Return
TV Setup
AIR CATV
Auto Program
Add Erase CH
Close Caption
VChip Control
System Setup
Return
Language
English
PC Setup
Color
H Position
V Position
Phase
Clock
Auto Adjust
Feature
Return
System Setup
STD
HRC
IRC
Auto
Return
Main Disp
TV
AV
S-Video
PC
CVI
Return
SETTING V-CHIP
25
V-Chip enables parents to prevent their children from watching inappropriate material on TV. V-Chip reads the ratings for
programming (except for news, sports, unedited movies on premium cable and Emergency System signals), then denies
access to programming if the program’s rating meets the limitations you select. In this case, the program will be blocked.
Press the POWER button 1 to turn on the TV; the POWER
indicator will light orange. Press the TV/VIDEO button 2
repeatedly to select the TV mode. Press the MENU button
3
; the Main Menu screen will appear. Press the
CHANNEL/Navigation UP 4 or DOWN 5 button to select
TV SETUP, then press the ENTER button 6 to select it.
Main Menu
Main Disp
Image Setup
Audio Setup
PC Setup
TV Setup
Language
Recall
Quit
Image Setup
Brightness
Contrast
Sharpness
Tint
Color
Return
Audio Setup
Treble
Bass
Balance
Return
PC Setup
Treble
Bass
Balance
Return
TV Setup
AIR CATV
Auto Program
Add Erase CH
Close Caption
VChip Control
System Setup
Return
Language
English
PC Setup
Color
H Position
V Position
Phase
Clock
Auto Adjust
Feature
Return
System Setup
STD
HRC
IRC
Auto
Return
Main Disp
TV
AV
S-Video
PC
CVI
Return
1
Press the CHANNEL/Navigation UP 1 or DOWN 2 button
until VCHIP CONTROL is selected, then press the ENTER
button 3 to select it. Using the Direct Channel Selection
/Number buttons (0-9) ❹, enter the password (“3308” is the
preset/default password if you have not changed it). This
password can be changed to consist of different numbers
(i.e. 1467, 3732) after the original password is entered. See
page 28 to change the password.
2
Once in the V-CHIP Control Menu, press the CHANNEL/
Navigation UP 1 or DOWN 2 button to select V-CHIP, then
press the ENTER button 3 to select it.
VChip Control
Set Password
VChip Lock
Class Optons
MPAA Options
Return
MPAA Options
G Blocked
PG Blocked
PG13 Blocked
R Blocked
NC17 Blocked
X Blocked
Return
Class Options
Set Password
- - - -
TV Y Unblocked
TY Y7 Unblocked
TV G Unblocked
TV PG Unblocked
TV 14 Unblocked
TV MA Unblocked
Return
VChip Lock
Off On
V-CHIP SET-UP
3
In the VChip Lock Menu, select Off (Unlock) or On (Lock)
using the VOLUME UP/Navigation Right 1 or VOLUME
DOWN/Navigation Left 2 button. Then, press the ENTER
button 3 to confirm the setting and return to the VCHIP
Control Menu.
VChip Control
Set Password
VChip Lock
Class Optons
MPAA Options
Return
MPAA Options
G Blocked
PG Blocked
PG13 Blocked
R Blocked
NC17 Blocked
X Blocked
Return
Class Options
Set Password
- - - -
TV Y Unblocked
TY Y7 Unblocked
TV G Unblocked
TV PG Unblocked
TV 14 Unblocked
TV MA Unblocked
Return
VChip Lock
Off On
4
