Identifying S
tatus Indicators
English
19
Job Tickets Icons
LED Indicator
The LED indicator shows the operational status of your radio.
Blinking red – Radio is transmitting at low battery condition,
receiving an emergency transmission or has failed the self-test
upon powering up.
Solid yellow – Radio is monitoring a digital conventional
channel. Also indicates fair battery charge when programmable
button is pressed.
Blinking yellow – Radio is scanning for activity or receiving a
Call Alert, or all local Linked Capacity Plus channels are busy.
In-Progress
• The text message to a group alias or ID is
pending transmission.
• The text message to a subscriber alias or ID is
pending transmission, followed by waiting for
acknowledgement.
All Jobs
Indicates all jobs listed.
New Jobs
Indicates new jobs.
OR
LED Indicator
