■ Components and options
Part Names and Functions
■ 1-cassette cabinet/2-cassette cabinet
No. Name Function
1 3rd Paper Cassette This holds approximately 500 sheets of paper. The paper size can
be changed easily.
2 4ht Paper Cassette (for the 2-cassette
cabinet)
Cabinet (for the 1-cassette cabinet) This can be used to store extra paper.
3 Right Lower Door Release Lever (C4) This lever allows access to jammed paper.
■ Duplex unit
No. Name Function
4 Duplex Unit Cover (C5) Open this cover to remove jammed paper in the duplex unit.
■ Finisher
No. Name Function
5 Finisher This is used to sort multiple copies into seperate respective stacks
where they can be stapled together.
■ Punch Kit
No. Name Function
6 Punch Kit Equipping the Finisher with this makes it possible to punch holes
in the copies.
2
3
4
5
1
6
