16 getting started – Muratec MFX-2830 User Manual
Page 34
Phone1
Phone2
Line
Network
Line2
>PS<
1-16
Getting
Started
Getting Started
No.
Name
Function
28
Power Jack
This is where the power cord is connected.
29
Network Connector
This is where the LAN cable is connected when network-related options are
installed.
30
Phone 1 Jack
This is used to connect the optional handset.
31
Phone 2 Jack
This is used to connect an external phone, such as an answering
machine.
32
Phone Jack
This is used to connect the phone line.
33
Second Phone Line Jack
This is used to connect the second phone line when the optional second
phone line module kit is installed.
28
29
30
31
32
33
