Mercedes-Benz 2004 E 320 - Manual (Page 393)

393
Technical data
Engine
Model E 55 AMG (211.076 1 )
1 The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corre-
sponding data of all special bodies and special equipment.
Engine 113
Mode of operation 4-stroke engine, gasoline injection
No. of cylinders 8
Bore 3.82 in (97.00 mm)
Stroke 3.60 in (92.00 mm)
Total piston displacement 331.8 cu.in. (5439 cm 3 )
Compression ratio 9:1
Output acc. to SAE J 1349 469 hp/6100 rpm
(350 kW/6100 rpm)
Maximum torque acc. to SAE J 1349 516 lb-ft/2650 rpm
(700 Nm/2650 rpm-4500 rpm)
Maximum engine speed 6500 rpm
Firing order 1-5-4-2-6-3-7-8
Poly-V-belts Belt one: 1289 mm
Belt two: 2449 mm
