Mercedes-Benz 2004 E 320 - Manual (Page 392)

392
Technical data
Engine
̄ Engine
Model E 320 (211.065 1 )
E 320 4MATIC (211.082 1 )
1 The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corresponding data of all special bodies and special equipment.
E 500 (211.070 1 )
E 500 4MATIC (211.083 1 )
Engine 112 113
Mode of operation 4-stroke engine, gasoline injection 4-stroke engine, gasoline injection
No. of cylinders 6 8
Bore 3.54 in (89.90 mm) 3.82 in (97.00 mm)
Stroke 3.31 in (84.00 mm) 3.31 in (84.00 mm)
Total piston displacement 195.2 cu.in. (3199 cm 3 ) 303.0 cu.in. (4966 cm 3 )
Compression ratio 10:1 10:1
Output acc. to SAE J 1349 221 hp/5600 rpm
(165 kW/5600 rpm) 302 hp/5600 rpm
(225 kW/5600 rpm)
Maximum torque acc. to SAE J 1349 232 lb-ft/3000 rpm-4800 rpm
(315 Nm/3000 rpm-4800 rpm) 339 lb-ft/2700 rpm-4250 rpm
(460 Nm/2700 rpm-4250 rpm)
Maximum engine speed 6000 rpm 6000 rpm
Firing order 1-4-3-6-2-5 1-5-4-2-6-3-7-8
Poly-V-belt 2390 mm 2390 mm
