23
At a glance
Instrument cluster
Item Page
1 L Left turn signal indi-
cator lamp
2 v Antilock Brake Sys-
tem (ABS)/Electronic
Stability Program
(ESP) warning lamp
311
3 Speedometer
4 Multifunction display
with:
Basic display with outside
temperature display 141
Status indicator with mal-
function warning message
Trip odometer 127
5 l Distance warning
lamp 1
1 Vehicles without Distronic*: Warning lamp without
function. It illuminates with the ignition on. It should
go out when the engine is running.
315
6 K Right turn signal indi-
cator lamp
Item Page
7 Coolant temperature dis-
play with:
• Coolant tempera-
ture warning lamp
314
8 Tachometer with:
1 Supplemental
restraint system
indicator lamp
316
- Antilock Brake Sys-
tem (ABS) malfunc-
tion indicator lamp
310
< Seat belt non-usage
warning lamp
315
A High beam head-
lamp indicator
123
9 Main odometer with:
ț Selector lever position 43
ț Program mode 164
Item Page
a Clock with: 143
; Brake warning
lamp, except
Canada
312
3 Brake warning
lamp, Canada only
312
? Engine malfunction
indicator lamp
313
b Fuel display with:
A Fuel reserve warn-
ing lamp
315
c Reset button for:
ț Resetting trip
odometer 127
ț Adjusting instrument
cluster illumination 126
ț Confirming new time
settings 143
