24 3. TV Connections
A/V Receiver (Sound System) Using
the TV’s Audio Output
Most setups require either a digital audio cable or
analog stereo audio cables. To send audio from TV
channels received on
ANT 1, ANT 2, or devices con-
nected directly to the TV, you must use one of the con-
nections shown below.
The TV makes all audio available in digital and analog
formats:
Analog audio coming into the TV is available as •
output in digital stereo format on the DIGITAL
AUDIO OUTPUT jack.
Digital incoming audio is available as analog output •
on the AVR AUDIO OUTPUT L and R jacks.
Usually, only one of the following audio connections is
required:
To connect an analog A/V receiver •
Connect left (white) and right (red) audio cables
from AVR AUDIO OUTPUT L and R on the TV back
panel to the TV AUDIO INPUT on the A/V receiver.
To connect a digital A/V receiver with • Dolby
Digital surround sound and PCM audio support:
Connect one end of the digital audio cable to
DIGITAL AUDIO OUTPUT on the back of the TV.
Connect the other end to the
COAXIAL DIGITAL
INPUT on the back of the A/V receiver.
HDMI
3D
GLASSES EMITTER
ANT 2
L
R
L R
(480i / 480p / 720p / 1080i) L R
DVI/PC INPUT VIDEO
Y Pb Pr
AUDIO
Pb Y/ VIDEO Pr
VIDEO: 480i/480p/720p/1080i/1080p AUDIO: PCM STEREO
PC: VGA, W-VGA, SVGA, W-SVGA,
XGA, W-ZGA, SXGA, 720p/ 1080p
1 2 3
HDMI
IR- NetCommand Output / External Controller Input
R
INPUT
3
INPUT
2
INP UT 1
S-VIDEO INPUT 3
AUDIO R L
AUDIO
ANT 2 / AUX
ANT 1 / MAIN
AVR AUDIO OUTPUT
DIGITAL AUDIO OUTPUT
AVR AUDIO OUTPUT
L
R
DIGITAL AUDIO OUTPUT
DIGITAL
AUDIO
OUTPUT
AVR
AUDIO
OUTPUT
L
R
$0"9*"-
*/165
015*$"-
*/165
$0"9*"-
*/165
%JHJUBMDPBYJBMDBCMF
GPSDPOOFDUJOHB
EJHJUBM"7SFDFJWFS
4UFSFPBOBMPHDBCMFT
GPSDPOOFDUJOHBO
BOBMPH"7SFDFJWFS
57CBDLQBOFM
"7SFDFJWFSCBDLQBOFM
Figure 11. Connecting the TV to an A/V receiver
Note:
On rare occasions, an HDMI signal may be •
copy-restricted and cannot be output from
the TV as a digital signal. To hear these copy-
protected signals through the A/V receiver, use
the connection for an analog A/V receiver.
Check the A/V receiver’s Owner’s Guide for
•
information concerning use of the digital input
and switching between digital sound and
analog stereo sound from the TV.
A/V Receiver with HDMI Output
Required: One HDMI-to-HDMI cable
This option allows you to view content from devices
connected to an A/V receiver. The A/V receiver can
send audio and video to the TV over a single HDMI
cable. You can use an HDMI connection as described
here in addition to an audio connection from the TV’s
audio output.
You may be able to use the TV’s remote control (with
slide switch set to
TV) to operate connected CEC-
enabled HDMI devices. Experiment with your equip-
ment to determine which functions are available to the
TV’s remote control. See Appendix E, “NetCommand
HDMI Control of CEC Devices” on page 77.
736 or 835 Series TV: This setup allows you to use
NetCommand-controlled audio and video switching over
the HDMI cable. See “A/V Receiver Control: Automatic
Audio and Video Switching via HDMI” on page 61.
HDMI
3D
GLASSES EMITTER
AVR AUDIO OUTPUT
DIGITAL AUDIO OUTPUT
L
R
L R
(480i / 480p / 720p / 1080i) L R
DVI/PC INPUT VIDEO
Y Pb Pr
AUDIO
Pb Y/ VIDEO Pr
VIDEO: 480i/480p/720p/1080i/1080p AUDIO: PCM STEREO
PC: VGA, W-VGA, SVGA, W-SVGA, XGA, W-XGA, SXGA, 720p/ 1080p
1 2 3
HDMI
IR- NetCommand Output / External Controller Input
R
INPUT
3
INPUT
2
INP UT 1 S-VIDEO INPUT 3
AUDIO R L
AUDIO
ANT 2 / AUX
ANT 1 / MAIN
HDMI
1 2 3
DIGITAL AUDIO OUTPUT
L
R
HDMI OUT
DIGITAL
AUDIO
OUTPUT
L
R
DIGITAL
AUDIO
L R
High-definition
DVD player
DVD player
Cable box
VCR
TV back panel
A/V receiver
with HDMI
output
Optional
analog or
digital audio
connection
Figure 12. A/V receiver connected to the TV with an
HDMI cable may offer special control capabilities.
