Monessen Hearth 624DV(ST - Manual (Page 38)

38 42D0200
Designer Series Gas Fireplaces CLEaNING and MaINTENaNCE
Make sure the gas valve knob is in the “OFF” position. Wait at least five (5) minutes before start-
ing maintenance. Fireplace must be cold before starting maintenance.
vENTING SySTEM
A qualified agency should examine the venting system annually.
CLEaNING GLaSS
Clean the tempered glass periodically. Condensation will some-
times form on the glass during a cold startup. This is normal for all
gas fireplaces. This condensation often attracts dust and lint to the
surface of the glass. The initial paint curing of the appliance can also leave a slight film on the
glass.
Your should clean the glass after the first two weeks of use. After that, you should clean the
glass no more than two or three times a season. Use a mild glass cleaner to clean the door. Do
not use abrasive cleaners. They will damage the glass surface.
PILoT aNd BuRNER FLaMES
FIREBox CLEaNING
1. Carefully remove log set, and embers (rock wool) from
combustion chamber.
2. Vacuum burner compartment thoroughly.
3. Vacuum or brush with soft brush any dust off logs.
4. Remove any lint from main burner and pilot.
5. Carefully replace log set, and embers in their correct
positions. Refer to Pages 34 through 36.
6. Replace door (if it has been removed).
7. Relight pilot. Refer to Page 37.
8. Turn on main burner.
C
au
TI
o
N
allow glass to cool before cleaning.
do not clean glass when it is hot.
damage could occur.
LG645
DV6000 log flames
Figure 54 -
Typical Burner Flame
LG645
Figure 55 -
Typical Pilot Flame
Thermopile
Thermocouple
FP2312
pilot flame
FP2312
Visually check pilot and burner flames periodically. Refer
to Figure 53 for typical burner flame. Refer to Figure 54 for
typical pilot flame.
w
a
RNING
Make sure clearances to combustibles
leave room for maintenance and ser-
vice.
w
a
RNING
Carefully reassemble and reseal fireplace
properly after any cleaning or servicing.
