30 42D0200
Designer Series Gas Fireplaces GLaSS REMovaL
GLaSS FRaME REMovaL
All three (3) glass frames are replaced the same way.
1. Release two clamps on bottom of fireplace. Figure 40
2. Tilt glass frame out and lift glass frame up until it clears three tabs on top of fireplace.
3. Set glass frame aside.
FP2310
remove glass
Figure 40 -
Remove Glass Frame
Glass Frame
Three
Tabs
Clamp
Clamp
FP2310
w
a
RNING
Each clamp has a quick spring force. when
reinstalling clamps, keep fingers clear. Remove
control panel to operate middle clamp on 500
and 600 units.
WARNING
!
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
