Qp305SLT/QpT305SLT CeNTRIFUgaL pUMp • opeRaTIoN aNd paRTS MaNUaL — Rev. #1 (10/11/10) — page 61
NOTICE
+ GX340K1PKT2: Model QP305SLT S/N 305SLT-0200 AND BELOW
, GX340U1PKT2: Model QP305SLT S/N 305SLT-0201 AND ABOVE.
HOnda GX340K1pKt2/GX340u1pKt2 — pistOn assY.
No. paRT No. PART NAME QTY. REMARKS
1 13010ZE3003 RING SET, PISTON- STANDARD 1
1, 13010ZE3005 RING SET, PISTON- STANDARD 1
1 13011ZE3003 RING SET, PISTON- OS 0.25 (OPTIONAL) 1
1, 13011ZE3005 RING SET, PISTON- OS 0.25 (OPTIONAL) 1
1 13012ZE3003 RING SET, PISTON- OS 0.50 (OPTIONAL) 1
1, 13012ZE3005 RING SET, PISTON- OS 0.50 (OPTIONAL) 1
1 13013ZE3003 RING SET, PISTON- 0.75 (OPTIONAL) 1
1, 13013ZE3005 RING SET, PISTON- 0.75 (OPTIONAL) 1
2 13101ZE3W00 PISTON- STANDARD 1
2 13102ZE3W00 PISTON- OS 0.25 (OPTIONAL) 1
2 13103ZE3W00 PISTON- OS 0.50 (OPTIONAL) 1
2 13104ZE3W00 PISTON- 0.75 (OPTIONAL) 1
3 13111ZF6000 PIN, PISTON 1
4+ 13200ZE3010 ROD ASSEMBLY, CONNECTING (STD.) ..........1................INCLUDES ITEM W/ *
4, 13200ZE3020 ROD ASSEMBLY, CONNECTING (STD.) ..........1................INCLUDES ITEM W/ *
4 13200ZE3315 ROD ASSEMBLY, CONNECTING- US 0.25 (OPT.) ..1................INCLUDES ITEM W/ *
5 * 90001ZE8000 BOLT, CONNECTING ROD 2
6 90601ZE3000 CLIP, PISTON PIN 20MM 2
