Qp305SLT/QpT305SLT CeNTRIFUgaL pUMp • opeRaTIoN aNd paRTS MaNUaL — Rev. #1 (10/11/10) — page 47
NOTICE
+ GX340K1PKT2: Model QP305SLT S/N 305SLT-0200 AND BELOW
, GX340U1PKT2: Model QP305SLT S/N 305SLT-0201 AND ABOVE.
HOnda GX340K1pKt2/GX340u1pKt2 — CYlinder barrel assY.
No. paRT No. PART NAME QTY. REMARKS
1+ 12000ZE3816 CYLINDER ASSEMBLY .....................................1................INCLUDES ITEMS W/ *
1, 12000ZE3416 CYLINDER ASSEMBLY .....................................1................INCLUDES ITEMS W/ #
2 15510ZE2043 SWITCH ASSEMBLY, OIL LEVEL 1
3 16541ZE3010 SHAFT, GOVERNOR ARM 1
4 32197ZE2003 SUB- HARNESS 1
5 90013883000 BOLT,FLANGE 6X12 (CT200) 1
6+ 90131896650 BOLT, DRAIN PLUG 2
6, 90131883000 BOLT, DRAIN PLUG 12X15 2
7 90446KE1000 WASHER 8.2X17X0.8 1
9 * # 91201ZE3004 OIL SEAL 35X52X8 1
10+ * 91201ZE9003 OIL SEAL 8X14X5 1
10,# 91203952771 OIL SEAL 8X14X5 1
11+ 91353671003 O- RING 13.5X1.5 1
11, 91353671004 O- RING 14MM, NOK 1
12 9405010000 NUT, FLANGE 10MM 1
13 9410912000 WASHER, DRAIN PLUG 12MM 2
14 9425110000 PIN, LOCK 10MM 1
15 957010601200 BOLT, FLANGE 6X12 2
16 * # 961006202000 BEARING, RADIAL BALL 6202 1
17 90013883000 BOLT, FLANGE 6X12 (CT200) 1
18 34150ZH7003 ALERT UNIT, OIL 1
