Qp305SLT/QpT305SLT CeNTRIFUgaL pUMp • opeRaTIoN aNd paRTS MaNUaL — Rev. #1 (10/11/10) — page 51
NOTICE
+ GX340K1PKT2: Model QP305SLT S/N 305SLT-0200 AND BELOW
, GX340U1PKT2: Model QP305SLT S/N 305SLT-0201 AND ABOVE.
HOnda GX340K1pKt2/GX340u1pKt2 — Fan COver assY.
No. paRT No. PART NAME QTY. REMARKS
1 16731ZE2003 CLIP, TUBE 1
2+ 19610ZE3010ZA COVER, FAN *R8* (BRIGHT RED) 1
2, 19610ZE3010ZB COVER, FAN *NH1* 1
2, 19610ZE3010ZL COVER, FAN *R280* 1
3 19631ZE3W00 SHROUD 1
5+ 36100ZH7003 SWITCH ASSEMBLY, ENGINE STOP 1
5, 36100ZF6P81 SWITCH ASSEMBLY, ENGINE STOP 1
7 90013883000 BOLT, FLANGE 6X12 (CT200) 6
8+ 90684ZA0601 CLIP, WIRE HARNESS 1
