page 10 —Qp305SLT/QpT305SLT CeNTRIFUgaL pUMp • opeRaTIoN aNd paRTS MaNUaL — Rev. #1 (10/11/10)
Figure 1. QP305SLT/QPT305SLT Dimensions
Table 1. Specifications (pump)
Model QP305SLT/QPT305SLT
Type High Pressure Centrifugal Pump
Suction Size 3.00 in. (76 mm.)
Discharge Size
1.00 in. (25 mm.) 2 ea.
1.50 in. (38 mm.) 1 ea.
Maximum Pumping Capacity
145 gallons/minute
(550 liters/minute)
Max. Lift 25 ft. (7.62 m)
Max. Head 328 ft. (100 m)
Dimension
(L x W x H)
28.0 x 20.5 x 23.8 in.
(71 x 52 x 60.5 cm.)
Dry Net Weight 110 lbs. (50 Kg.)
speCiFiCatiOns/diMensiOns (puMp)
