Qp305SLT/QpT305SLT CeNTRIFUgaL pUMp • opeRaTIoN aNd paRTS MaNUaL — Rev. #1 (10/11/10) — page 49
NOTICE
+ GX340K1PKT2: Model QP305SLT S/N 305SLT-0200 AND BELOW
, GX340U1PKT2: Model QP305SLT S/N 305SLT-0201 AND ABOVE.
HOnda GX340K1pKt2/GX340u1pKt2 — CYlinder Head assY.
No. paRT No. PART NAME QTY. REMARKS
1+ 12200ZF6W00 CYLINDER HEAD 1
1+ 12200ZF6W01 CYLINDER HEAD 1
1, 12200ZF6406 CYLINDER HEAD 1
2 12204ZE2306 GUIDE, EX. VALVE OS (OPTIONAL) 1
3 12205ZE2305 GUIDE, EX. VALVE OS (OPTIONAL) 1
4 12216ZE2300 CLIP, VALVE GUIDE 1
5 12251ZE3W00 GASKET, CYLINDER HEAD 1
6 12310ZE2020 COVER, HEAD 1
7+ 12315ZE3840 TUBE, BREATHER 1
7, 950051110530 TUBE, BREATHER 11X105 ...............................1................REPLACES 950051100130M
8 12391ZE2020 GASKET, CYLINDER HEAD COVER 1
10 90014ZE2000 BOLT, HEAD COVER 1
11 90042ZE8000 BOLT, STUD 8X131.5 2
12 92900080320E BOLT 2, STUD 8X32 2
13 90441ZE2010 WASHER, HEAD COVER 1
14 9430112200 PIN A, DOWEL 12X20 1
15+ 957011008000 BOLT, FLANGE 10X80 4
15, 957251008000 BOLT, FLANGE 10X80 4
16 9807955846 SPARK PLUG, BPR5ES (NGK), OPT. 1
16 9807955855 SPARK PLUG , W16EPR- U (DENSO), 1
OPTIONAL
16 9807956846 SPARK PLUG, BPR6ES (NGK) 1
16 9807956855 SPARK PLUG, W20EPR- U (DENSO) 1
