Qp305SLT/QpT305SLT CeNTRIFUgaL pUMp • opeRaTIoN aNd paRTS MaNUaL
— Rev. #1 (10/11/10) — page 43
NOTICE
+ GX340K1PKT2: Model QP305SLT S/N 305SLT-0200 AND BELOW
, GX340U1PKT2: Model QP305SLT S/N 305SLT-0201 AND ABOVE.
No.
paRT No.
PART NAME
QTY.
REMARKS
1+$
06165ZE3000
GOVERNOR KIT, OPTIONAL ............................1................INCLUDES ITEMS W/ #
2+
11300ZE3602
COVER ASSEMBLY, CRANKCASE Q- TYPE ...1................INCLUDES ITEMS W/ $
2,
11300ZE3604
COVER ASSEMBLY, CRANKCASE ...................1................INCLUDES ITEM W/@
3+
11381ZE3800
GASKET, CASE COVER
1
3@
11381ZE3801
GASKET, CASE COVER
1
4
15600ZG4003
CAP ASSEMBLY, OIL FILLER ...........................1................INCLUDES ITEM W/ %
5
15600735003
CAP ASSEMBLY, OIL FILLER ...........................1................INLCUDES ITEM W/ +
7%
15625ZE1003
GASKET, OIL FILLER CAP
1
8+
15625ZE1003
GASKET, OIL FILLER CAP
1
9#$
16510ZE3000
GOVERNOR ASSEMBLY ..................................1................INCLUDES ITEMS W/
*
10
*
#$ 16511ZE8000
WEIGHT, GOVERNOR
3
11
*
#$ 16512ZE3000
HOLDER, GOVERNOR WEIGHT
1
12
*
#$ 16513ZE2000
PIN, GOVERNOR WEIGHT
3
13+#$ 16531ZE2000
SLIDER, GOVERNOR
1
13,#$ 16531Z0A000
SLIDER, GOVERNOR
1
15#$ 90602ZE1000
CLIP, GOVERNOR HOLDER
1
16
90701HC4000
PIN, DOWEL 8X12
2
17$
91201ZE3004
OIL SEAL 35X52X8
1
18#$ 9410106800
WASHER, PLAIN 6MM
1
19
957010804000
BOLT, FLANGE 8X40
7
20$
961006202000
BEARING, RADIAL BALL 6202
1
21$
961006207000
BEARING, RADIAL BALL 6207
1
HOnda GX340K1pKt2/GX340u1pKt2 — CranKCase COver assY.
