Qp305SLT/QpT305SLT CeNTRIFUgaL pUMp • opeRaTIoN aNd paRTS MaNUaL — Rev. #1 (10/11/10) — page 55
NOTICE
+ GX340K1PKT2: Model QP305SLT S/N 305SLT-0200 AND BELOW
, GX340U1PKT2: Model QP305SLT S/N 305SLT-0201 AND ABOVE.
HOnda GX340K1pKt2/GX340u1pKt2 — Fuel tanK assY.
No. paRT No. PART NAME QTY. REMARKS
1 16854ZH8000 RUBBER, SUPPORTER 107MM 1
2 16955ZE1000 JOINT, FUEL TANK 1
3+ 17510ZE3020ZA TANK, FUEL (BLACK) 1
3, 17510ZE30800ZA TANK, FUEL *NH1* 1
3, 17510ZE3800ZC TANK, FUEL *NH31* 1
5+ 17620ZH7023 CAP, FUEL FILLER 1
5, 17620Z0T305 CAP, FUEL FILLER CHROME PLATED 1
6+ 17631ZH7003 GASKET, FUEL FILLER CAP 1
6, 17631Z0T812 GASKET, FUEL FILLER CAP 39X62X3 1
7 17672ZE2W01 FILTER, FUEL 1
10+ 91353671003 O- RING 13.5X1.5 (ARA) 1
10, 91353671004 O- RING 14MM NOK 1
11 9405008000 NUT, FLANGE 8MM 2
12+ 950014500360M BULK HOSE, FUEL (4.5X3000) (4.5X235) 1
12, 950014523540 BULK HOSE, FUEL 4.5X235 .............................1................REPL.950014500160M
S/N 1030950 AND BELOW
12, 91424Z5L801 BULK HOSE, FUEL 4.5X235 FKM ....................1................S/N 1030951 AND ABOVE
13+ 9500202080 CLIP, TUBE B8 2
13, 9500202080 CLIP, TUBE B8 ...................................................2................S/N 1030950 AND BELOW
13, 950024080008 CLAMP, TUBE D8 ..............................................2................S/N 1030951 AND ABOVE
14 957010802500 BOLT, FLANGE 8X25 2
