Multiquip High Pressure Centrifugal Pump (Honda GX340K1PKT2/GX340U1PKT2 Gasoline Engine) QPT305SLT - Manual (Page 59)

Qp305SLT/QpT305SLT CeNTRIFUgaL pUMp • opeRaTIoN aNd paRTS MaNUaL — Rev. #1 (10/11/10) — page 59
NOTICE
+ GX340K1PKT2: Model QP305SLT S/N 305SLT-0200 AND BELOW
, GX340U1PKT2: Model QP305SLT S/N 305SLT-0201 AND ABOVE.
HOnda GX340K1pKt2/GX340u1pKt2 — MuFFler assY.
No. paRT No. PART NAME QTY. REMARKS
1 18310ZE3003 MUFFLER 1
2 18320ZE3G10 PROTECTOR, R. MUFFLER 1
3 18325ZE3G10 PROTECTOR, L. MUFFLER 1
4 18330ZE2000 PIPE, EX. 1
5 18336ZE3000 FLANGE, BAFFLE 1
7 18381ZE2800 GASKET, MUFFLER 1
9 90050ZE1000 SCREW, TAPPING 5X8 8
10 9405008000 NUT, FLANGE 8MM 3
12 18333ZE3800 GASKET, EX. PIPE 1
13, 18355ZE3010 ARRESTER, SPARK 1
14, 9405008000 NUT FLANGE, 8MM 2
