Managing Through the Mini Console 53
Configuring the Unit
1. Select UNIT CONFIGURATION from the Main Menu.
Unit Config Main Menu
2. Press to go to the UNIT CONFIGURATION menu.
3. Press to scroll through each configuration option.
4. Press to go to the next level of the configuration menu.
The following lists Unit Configuration options:
Unit Configuration Options
Console Lock Lock
Network Config IP Address, Subnet Mask and Default Gateway
Set Password Set new password
System Restart Restart hub
System Default Reset hub to factory configuration
EIA232 Config Baud Rate
Locking the Mini Console
In the console lock configuration menu, the text string “LOCK” displays in
the Message Zone. If the device is currently locked, a lock symbol also
displays on the right side of the Mini Console.
ID
Master
WWW
SNMP
O-O-B
10
20
40
1
3
5
80
K % 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 G-A
G-B
G-C
G-D
