GXP-2000 User Manual
Grandstream Networks, Inc.
- 37 -
Auto Upgrade When set toYes, device will do HTTP upgrade and provisioning.
In “Check for new firmware every” field, enter the number of days to
enable GXP-2000 to check the HTTP server for firmware upgrade or
configuration in the defined period of days.
When set to No, GXP-2000 will only do HTTP download at boot up.
Voice Mail User
ID When configured, user will be able to dial voice mail server by
pressing “MSG” button.
Subscribe for
MWI: Default is NO. When set to “Yes” a SUBSCRIBE for Message
Waiting Indication will be sent periodically.
Auto Answer When configured to Yes, the device will automatically switch to
speaker when this is a incoming call
Offhook
Auto-Dial This parameter allows users to configure a User ID or extension
number to be automatically dialed upon offhook. Please note that only
the user part of a SIP address needs to be entered here. The GXP-
2000 will automatically append the “@” and the host portion of the
corresponding SIP address.
Enable Call
Features Default is No. If set to Yes, Call Forwarding & Do-Not-Disturb are
supported locally
Disable Call
Waiting Default is No.
Send DTMF This parameter controls how DTMF events are transmitted. There are
3 ways: in audio which means DTMF is combined in audio signal
(not very reliable with low-bit-rate codec), via RTP (RFC2833), or
via SIP INFO.
DTMF Payload
Type This parameter sets the payload type for DTMF using RFC2833
Send Flash
Event This parameter allows users to control whether to send an SIP
NOTIFY message indicating the Flash event, or just to switch to the
voice channel when users press the Flash key.
NTP server This parameter defines the URI or IP address of the NTP server which
is used by the GXP-2000 to display the current date/time.
