GXP-2000 User Manual
Grandstream Networks, Inc.
- 11 -
Hardware Feature:
• Graphic LCD that can display 64(rows) x 131 (columns) in pixels
• Support up to 11 line calls and 7 speed dial keys. (Current firmware support 4 line
with 7 speed dial keys)
• Support Power over Ethernet (PoE) IEEE standard 802.3af, power can be drawn
from either spare line or data line.
Note: GXP-2000 will use power from power adapter whenever it is plugged in.
• Support Headset which will auto switch to Headset when plugged in
• Support 10/100 Full/Half Duplex Ethernet Switch with LAN and PC port,
Ethernet polarity can be auto detected, thus either straight through or twist cable
can be used.
• Support Message Waiting Indication LED
3.2 Hardware Specification
The table below describes the hardware specification of GXP-2000:
Model
GXP-2000
LAN interface 2xRJ45 10/100Base-T with PoE (802.3af)
Power over Ethernet IEEE 802.3af standard, can draw power from both
spare lines or signal lines from Ethernet
Headset Jack 3.5mm Headset port
LED 11 LED with different light pattern in RED color
Universal Switching
Power Adaptor Input: 100-240VAC 50-60 Hz
Output: +5VDC, 1200mA,
UL certified
Dimension 215mm (W)
220mm (D)
57mm (H)
Weight 0.82kg (1.8lbs)
Temperature 40 - 130 o F
5 – 45 o C
Humidity 10% - 90%
(non-condensing)
