Gas-Fired Products PTS Series 100 - Manual (Page 7)

Form #43343530
–6– JJuly 08
BURNER PACKAGE NUMBERS:
NATURAL GAS PROPANE GAS
MODEL NO PART NO.
PTS/U 40-N7 #44149510
PTS/U 50-N7 #44149530
PTS/U 75-N7 #44149550
PTS/U 100-N7 #44149570
PTS/U 125-N7 #44149590
PTS/U 150-N7 #44149610
PTS/U 175-N7 #44149630
PTS/U 200-N7 #44149650
MODEL NO PART NO.
PTS/U 40-L7 #44149520
PTS/U 50-L7 #44149540
PTS/U 75-L7 #44149560
PTS/U 100-L7 #44149580
PTS/U 125-L7 #44149600
PTS/U 150-L7 #44149620
PTS/U 175-L7 #44149640
PTS/U 200-L7 #44149660
B) PTS 40-200 Body Package Descriptions
(Package Part Number is indicated on the outside of each corresponding carton.)
System Lengths
PTS Body Packages – Aluminized/Hot Rolled or
Alumi-Therm/Hot Rolled
10 Ft.
44134020
20 Ft. pkg
44135000
30 Ft. pkg
44136000
40 Ft. pkg
44137100
50 Ft. pkg
44138100
Part # Each Body Package Includes: Qty. Qty. Qty. Qty. Qty.
42912080 10 Ft. Tube with 24 Hole Flange (Aluminized) 1 1 1 - -
42912169 10 Ft. Tube with 6 Hole Flange (Alumi-Therm) - - - 1 1
41932101 10 Ft. Tube less Flanges (Hot Rolled) - 1 2 3 4
43319100 Reflector, 9’ 11½” 1 2 3 4 5
30462980 Tube Coupling - 1 2 3 4
43318000 Tube Hanger/Support Bracket, 13” 1 2 3 4 5
43980010 Wire Hanger 1 2 3 4 5
Body Fastener Kit (included in body packages) 42907280 42907190 42907200 42907210 42907220
42873000 U-Bolt 1 2 3 4 5
02127110 Hex Nut, 5/16-18 3 5 6 8 10
02189020 HWHSM Screw, #10-16 x ½” TEKS 4 8 10 14 18
60Ft. System 70Ft. System
PTS Body Packages – Alumi-Therm/Hot Rolled
40 Ft. Pkg
44137100
20 Ft. Pkg
44135010
40 Ft. Pkg.
44137100
30 Ft. Pkg
44136040
Part # Each Body Package Includes: Qty. Qty. Qty. Qty.
42912169 10 Ft. Tube with 6 Hole Flange (Alumi-Therm) 1 - 1 -
41932101 10 Ft. Tube less Flanges (Hot Rolled) 3 2 3 3
43319100 Reflector, 9’ 11½” 4 2 4 3
30462980 Tube Coupling 3 2 3 3
43318000 Tube Hanger/Support Bracket, 13” 4 2 4 3
43980010 Wire Hanger 4 2 4 3
Body Fastener Kit (included in body packages) 42907210 42907190 42907210 42907200
42873000 U-Bolt 4 2 4 3
02127110 Hex Nut, 5/16-18 8 5 8 6
02189020 HWHSM Screw, #10-16 x ½” TEKS 14 8 14 10
