Gas-Fired Products PTS Series 100 - Manual (Page 15)

Form #43343530
–14– JJuly 08
8.1) DIMENSIONS – PTU Series
Typical Dimensions Up to 50 Ft. Shown.
Models:
PTU 40, 50,
75
Models:
PTU 50, 75,
100, 125
Models:
PTU 100, 125,
150, 175
Models:
PTU 125, 150,
175, 200
300”
(762cm)
108”
(274cm)
12”
(30cm)
12”
(30cm)
Bottom View
Wire Hangers
(typical)
108”
(274cm)
12”
(30cm)
240”
(610cm)
108”
(274cm)
180”
(457cm) 108”
(274cm)
12”
(30cm)
48”
(122cm)
5 FT Tube
Assembly
14”
(36cm)
120”
(305cm)
108”
(274cm)
Burner
Box
Flue
Terminal
10 FT Tube
Assembly
(typical)
15”
(38cm)
108”
(274cm)
48”
(122cm)
31” Tube Support/
Hanger Brackets
(typical at control end)
Shipped with
U-Bend Package
Wire Hangers
(typical)
U-Bend
13” Tube Support/
Hanger Brackets
(typical)
4” Tube Coupling
(typical)
13” Tube Support/
Hanger Brackets
(typical)
6”
(16cm)
Flue Terminal
18” (46cm)
31” (79cm)
PTU (end view)
Burner
Box
U-Bend
31” Tube Support/
Hanger Bracket
10”
(25cm)
14-1/2”
(37cm)
Fresh Air
Inlet
1/2” MPT Gas
Connection
120VAC
Power Supply Cord
