6 www.goodmanmfg.com SS-CPC90-150 SS-CPC90-150 www.goodmanmfg.com 7
P
roduct
S
PecificationS
P
roduct
S
PecificationS
P
roduct
S
PecificationS
— 12½ t
onS
CPC150
***3B***A*
CPC150
***4B***A*
CPC150
***7B***A*
Cooling Capacity
Total, BTU/h
140,000 140,000 140,000
Sensible BTU/h 98,000 98,000 98,000
EER / IEER 11.0 / 11.2 11.0 / 11.2 11.0 / 11.2
Decibels 83 83 83
ARI Reference #s 5104773 5104773 5104773
Evaporator Motor / Coil
Motor Type
Belt Drive Belt Drive Belt Drive
Indoor Nominal CFM 4,200 4,200 4,200
Indoor Motor FLA (Cooling) 9.4 4.7 4.2
Horsepower - RPM 3.0 - 1,725 3.0 - 1,725 3.0 - 1,725
Piston Size (Cooling) 0.096 0.096 0.096
Filter Size (4) 20" x 25" x 2" (4) 20" x 25" x 2" (4) 20" x 25" x 2"
Drain Size (NPT) ¾" ¾" ¾"
R-410A Refrigerant Charge Cir #1 & #2 285 oz. 285 oz. 285 oz.
Evaporator Coil Face Area (ft 2 ) 14.7 14.7 14.7
Rows Deep / Fins per Inch 4 / 15 4 / 15 4 / 15
Condenser Fan / Coil
Quantity of condenser Fan Motors
2 2 2
Horsepower - RPM ⅓ - 1,075 ⅓ - 1,075 ⅓ - 1,075
Fan Diameter / # Fan Blades 22/3 22/3 22/3
Outdoor Nominal CFM 8,400 8,400 8,400
Face Area (ft 2 ) 35.3 35.3 35.3
Rows Deep - Fins per Inch 2/3 rows - 15 fpi 2/3 rows - 15 fpi 2/3 rows - 15 fpi
Belt Drive Evap Fan Data
# of Wheels (D x W)
(1) 15" x 15" (1) 15" x 15" (1) 15" x 15"
Motor Sheave / Blower Sheave VL40 / AK66 VL40 / AK66 VL40 / AK66
Belt AX49 AX49 AX49
Compressor
Quantity / Type / Stage
2 / Scroll / 1 2 / Scroll / 1 2 / Scroll / 1
Compressor RLA / LRA ea. 22.4 / 149 10.6 / 75 7.7 / 54
Electrical Data / Static
Voltage / Phase / Frequency
208-230/3/60 460/3/60 575/3/60
Outdoor Fan FLA ea. 2.4 1.2 0.9
Total Unit Amps 59 28 21.4
Min. Circuit Ampacity 1 65 31 23
Max. Overcurrent Protection (amps) 2 80 40 30
Entrance Power Supply Locating
Dimple
Locating
Dimple
Locating
Dimple Entrance Control Voltage
Operating Weight (lbs) 1275 1275 1275
Ship Weight (lbs) 1300 1300 1300
¹ Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
² May use fuses or HACR-type circuit breakers of the same size as noted.
Notes
• Always check the S&R plate for electrical data on the unit being installed.
• When a factory-installed powered convenience outlet is installed in the equipment, the unit MCA (Min. Circuit Ampacity) will increase by 7.5A for
208/230V units, increase by 3.75A for 460V, units and by 3A for 575V units. The MOP (Max. Overcurrent Protection) device must be sized accordingly.
