18 www.goodmanmfg.com SS-CPC90-150 SS-CPC90-150 www.goodmanmfg.com 19
P
roduct
S
PecificationS
P
roduct
S
PecificationS
a
irflow
d
ata
— 10 t
ons
Standard Belt Drive & Two-Speed Standard Belt-Drive at High Speed — Down Shot
ESP
(“ W.C.)
Turns Open
0 1 2 3 4 5
CFM RPM BHP CFM RPM BHP CFM RPM BHP CFM RPM BHP CFM RPM BHP CFM RPM BHP
0.2 --- --- --- --- --- --- 4632 781 1.76 4203 742 1.41 3927 691 1.17 3510 658 0.9
0.4 --- --- --- 4488 825 1.85 4183 783 1.54 3733 748 1.23 3512 693 1 --- --- ---
0.6 4442 880 2.02 4066 830 1.63 3717 786 1.31 --- --- --- --- --- --- --- --- ---
0.8 4001 885 1.77 3622 835 1.41 --- --- --- --- --- --- --- --- --- --- --- ---
1 3603 890 1.55 --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
1.2 --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
High-Static Belt-Drive — Down Shot
ESP
(“ W.C.)
Turns Open
0 1 2 3 4 5
CFM RPM BHP CFM RPM BHP CFM RPM BHP CFM RPM BHP CFM RPM BHP CFM RPM BHP
0.8 --- --- --- --- --- --- --- --- --- --- --- --- 4435 940 2.22 4078 886 1.82
1 --- --- --- --- --- --- --- --- --- 4462 997 2.47 4103 945 2.05 3539 892 1.52
1.2 --- --- --- --- --- --- 4513 1054 2.75 4127 1003 2.26 3568 950 1.71 --- --- ---
1.4 --- --- --- --- --- --- 4126 1064 2.52 3597 1008 1.92 --- --- --- --- --- ---
1.6 --- --- --- 4438 1116 2.97 3759 1069 2.25 --- --- --- --- --- --- --- --- ---
1.8 --- --- --- 3956 1124 2.55 --- --- --- --- --- --- --- --- --- --- --- ---
2 4050 1179 3.05 3473 1132 2.32 --- --- --- --- --- --- --- --- --- --- --- ---
Standard Belt Drive & Two-Speed Standard Belt-Drive at High Speed — Horizontal
ESP
(“ W.C.)
Turns Open
0 1 2 3 4 5
CFM RPM BHP CFM RPM BHP CFM RPM BHP CFM RPM BHP CFM RPM BHP CFM RPM BHP
0.2 --- --- --- --- --- --- --- --- --- 4562 736 1.58 4253 691 1.29 3893 642 1
0.4 --- --- --- --- --- --- 4497 780 1.7 4200 736 1.41 3735 691 1.06 3322 648 0.83
0.6 --- --- --- 4467 824 1.81 4221 784 1.55 3689 741 1.18 --- --- --- --- --- ---
0.8 4564 873 2.06 4170 830 1.68 3677 785 1.29 --- --- --- --- --- --- --- --- ---
1 4129 875 1.81 3498 835 1.34 --- --- --- --- --- --- --- --- --- --- --- ---
1.2 3558 879 1.49 --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
High-Static Belt-Drive — Horizontal
ESP
(“ W.C.)
Turns Open
0 1 2 3 4 5
CFM RPM BHP CFM RPM BHP CFM RPM BHP CFM RPM BHP CFM RPM BHP CFM RPM BHP
0.8
DO NOT
OPERATE
--- --- --- --- --- --- --- --- --- --- --- --- 4602 884 2.13
1 --- --- --- --- --- --- --- --- --- 4749 940 2.44 4180 885 1.89
1.2 --- --- --- --- --- --- --- --- --- 4251 945 2.12 3642 896 1.58
1.4 --- --- --- --- --- --- 4443 1001 2.5 3744 951 1.8 --- --- ---
1.6 --- --- --- 4587 1056 2.82 3971 1006 2.17 --- --- --- --- --- ---
1.8 4760 1105 3.23 4071 1061 2.43 3342 1012 1.86 --- --- --- --- --- ---
2 4364 1114 2.91 3579 1067 2.05 --- --- --- --- --- --- --- --- ---
Notes :
Assume dry coil with filter in place; CFM correction for wet coil = 3%
Any adjustment made to the blower should not cause the motor to draw more than the motor rated RLA. Applications that exceed the above could require a
larger motor. Minimum rated SCFM is 350 per ton.
