h
eat
k
it
e
leCtriCal
d
ata
(B
lower
o
nly
, h
eat
m
ode
) — 7½ t
ons
Model and
Heat Kit Usage
MCA¹
at 208 / 240V
MOP² (amps)
at 208 / 240V
Actual kW
at 240V
Recommended
Airflow Range
CPC090***3B***
37
50
---
---
EHK3-16
51
60
15
3000 - 3375 CFM
EHK3-30
97
100
30
3000 - 3375 CFM
EHK3-45
136
150
43
3000 - 3375 CFM
Model and
Heat Kit Usage
MCA¹
at 480V
MOP² (amps)
at 480V
Actual kW
at 480V
Recommended
Airflow Range
CPC090***4B***
18
20
---
---
EHK4-16
26
30
15
3000 - 3375 CFM
EHK4-30
48
50
30
3000 - 3375 CFM
EHK4-45
68
70
43
3000 - 3375 CFM
Model and
Heat Kit Usage
MCA¹
at 575V
MOP² (amps)
at 575V
Actual kW
at 575V
Recommended
Airflow Range
CPC090***7B***
13
15
---
---
EHK7-16
22
25
15
3000 - 3375 CFM
EHK7-30
41
45
30
3000 - 3375 CFM
EHK7-45
57
60
43
3000 - 3375 CFM
¹ Minimum Circuit Ampacity
² Maximum Overcurrent Protection device
m
inimUm
a
irflow
for
e
leCtriC
h
eat
Heater Size (kW)
Minimum CFM
15
3,000
30
3,000
43
3,000
kw C
orreCtion
f
aCtors
kW Correction Factor (for 1- & 3-Phase Units)
Supply Voltage
240
230
220
210
208
Correction Factor
1
0.93
0.82
0.78
0.76
kW Correction Factor (for 480V Units)
Supply Voltage
460
440
430
Correction Factor
0.92
0.84
0.8
For other voltage, use voltage² / 480²
kW Correction Factor (for 575V Units)
Supply Voltage
560
550
540
Correction Factor
0.95
0.91
0.88
Multiply rated kW by correction factor to get actual kW.
