4 www.goodmanmfg.com SS-CPC90-150 SS-CPC90-150 www.goodmanmfg.com 5
P
roduct
S
PecificationS
P
roduct
S
PecificationS
P
roduct
S
PecificationS
— 8½ t
onS
CPC102
***3B***A*
CPC102
***4B***A*
CPC102
***7B***A*
Cooling Capacity
Total BTU/h
102,000 102,000 102,000
Sensible BTU/h 70,380 70,380 70,380
EER / IEER 11.3 / 11.4 11.3 / 11.4 11.3 / 11.4
Decibels 83 83 83
ARI Reference #s 5104771 5104771 5104771
Evaporator Motor / Coil
Motor Type
Belt Drive Belt Drive Belt Drive
Indoor Nominal CFM 3,200 3,200 3,200
Indoor motor FLA (Cooling) 7.8 3.9 2.3
Horsepower - RPM 1725 1725 1725
Piston Size (Cooling) 0.08 0.08 0.08
Filter Size (Qty) (4) 16 x 20 x 2 (4) 16 x 20 x 2 (4) 16 x 20 x 2
Drain Size (NPT) 3/4" 3/4" 3/4"
R-410A Refrigerant Charge Cir #1 & #2 180 oz. 180 oz. 180 oz.
Evaporator Coil Face Area (ft²) 8.9 8.9 8.9
Rows Deep / Fins per Inch 4 / 16 4 / 16 4 / 16
Belt Drive Evap Fan Data
# of Wheels (D x W)
1 (15" x 12") 1 (15" x 12") 1 (15" x 12")
Motor Sheave / Blower Sheave VL40 / AK74 VL40 / AK74 VL40 / AK74
Belt AX51 AX51 AX51
Condenser Fan / Coil
Quantity of Condenser Fan Motors
2 2 2
Horsepower - RPM 1/4" - 1,090 1/4" - 890 1/4" - 1,075
Fan Diameter / # Fan Blades 22 / 4 22 / 4 22 / 4
Outdoor Nominal CFM 7,200 7,200 7,200
Face Area (ft²) 27 27 27
Rows Deep - Fins per Inch 2 / 22 2 / 22 2 / 22
Compressor
Quantity / Type / Stage
2 / Scroll / 1 2 / Scroll / 1 2 / Scroll / 1
Compressor RLA / LRA ea. 14.5 / 98 6.3 / 55 6.0 / 41
Electrical Data
Voltage/Phase/ Frequency
230 / 3 / 60 460 / 3 / 60 575 / 3 / 60
Standard Max Static 1" 1 1
Outdoor Fan RLA ea. 1.4 0.8 0.6
Total Unit Amps 39.6 18.1 15.5
Min. Circuit Ampacity¹ 43.2 19.7 17
Max. Overcurrent Protection (amps)² 50 25 20
Entrance Power Supply Locating
Dimple
Locating
Dimple
Locating
Dimple Entrance Control Voltage
Operating Weight (lbs)
975 975 975
Ship Weight (lbs) 1000 1000 1000
¹ Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
² May use fuses or HACR-type circuit breakers of the same size as noted.
Notes
• Always check the S&R plate for electrical data on the unit being installed.
• When a factory-installed powered convenience outlet is installed in the equipment, the unit MCA (Min. Circuit Ampacity) will increase by 7.5A for
208/230V units, increase by 3.75A for 460V units, and by 3A for 575V units. The MOP (Max. Overcurrent Protection) device must be sized accordingly.
