-64-
Extreme series Jointer (Mfg. since 9/11)
G9953/G9953ZX/G9953ZXF Fence parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
201 P9953201 TUBE ROD BRACKET 222 PSS01M SET SCREW M6-1 X 10
202 P9953202 CONNECTOR LEFT 223 PSS03M SET SCREW M6-1 X 8
203 P9953203 CONNECTOR RIGHT 224 PB26M HEX BOLT M8-1.25 X 30
204 P9953204 BASE PLATE 225 PW01M FLAT WASHER 8MM
205 PSB71M CAP SCREW M10-1.5 X 60 226 PN02M HEX NUT M10-1.5
206 PLW04M LOCK WASHER 8MM 227 PB73M HEX BOLT M10-1.5 X 50
207 PSB05M CAP SCREW M8-1.25 X 50 228 PB07M HEX BOLT M8-1.25 X 25
208 PSB64M CAP SCREW M10-1.5 X 25 229 PSB01M CAP SCREW M6-1 x 16
209 PW03M FLAT WASHER 6MM 230 P9953230 BRACKET
210 PSB04M CAP SCREW M6-1 X 10 231 P9953231 ANCHOR ROD
211 P9953211 GEAR SHAFT 232 P9953232 PIVOT PIN RIGHT
212 P9953212 HANDWHEEL 233 P9953233 PIVOT PIN LEFT
213 PW02 FLAT WASHER 3/8 234 P9953234 FENCE ROD
214 P9953214 HANDLE 3/8-16 235 P9953235 PIVOT ARM
215 PSS16M SET SCREW M8-1.25 X 10 236 P9953236 FENCE ANGLE SEAT
216 PN03M HEX NUT M8-1.25 237 P9953237 FENCE ROD BRACKET
217 PSS21M SET SCREW M8-1.25 X 25 238 P9953238 PIVOT ROD
218 P9953218 LOCK LEVER 1/2 X 50MM 239 P9953239 FENCE
219 P9860221 KNOB 3/8" 240 P9953240 FENCE ROD
220 P9860220 FENCE ADJUSTMENT HANDLE 241 PSB06M CAP SCREW M6-1 X 25
221 PW03M FLAT WASHER 6MM
