-10-
Extreme series Jointer (Mfg. since 9/11)
Note: The circuit requirements listed in this man-
ual apply to a dedicated circuit—where only one
machine will be running at a time. If this machine
will be connected to a shared circuit where mul-
tiple machines will be running at the same time,
consult a qualified electrician to ensure that the
circuit is properly sized for safe operation.
Serious injury could occur if you connect
the machine to power before completing the
setup process. DO NOT connect to power
until instructed later in this manual.
circuit Requirements for G9953/
G9953ZX
Full-Load current Rating ................... 25 amps
Nominal voltage .............................. 220v/240v
cycle ..........................................................60 hz
phase .................................................... 1-phase
circuit Rating ...................................... 30 amps
plug/Receptacle ...........................NEMa L6-30
cord .........3-Wire, 10 aWG, 300vac, “S”-Type
Figure 4. typical l6-30 plug and receptacle.
^h=dd`ZY
8jggZci8Vggn^c\Egdc\h
L6-30 GROUNDED
LOCKING
RECEPTACLE
L6-30
LOCKING
PLUG
G9953 &
G9953ZX
G9953ZXF circuit Requirements for
220v Operation
Full-Load current Rating ................... 14 amps
Nominal voltage .............................. 220v/240v
cycle ..........................................................60 hz
phase .................................................... 3-phase
circuit Rating ...................................... 20 amps
connection ......hardwire with Locking Switch
G9953ZXF circuit Requirements for
440v Operation
I]^h bVX]^cZ XVc WZ XdckZgiZY id deZgViZ dc V
))%KedlZghjeeangZ[Zgid
Voltage Conversion
^chigjXi^dchi]Vi]VhVkZg^[^ZY\gdjcYVcYbZZih
i]Z[daadl^c\gZfj^gZbZcih/
Full-Load current Rating ..................... 7 amps
Nominal voltage .............................. 440v/480v
cycle ..........................................................60 hz
phase .................................................... 3-phase
Rated Size ........................................... 15 amps
connection ......hardwire with Locking Switch
Figure 5. typical setup of a permanently
connected machine.
EdlZg
HdjgXZ
AdX`^c\
9^hXdccZXiHl^iX]
BVX]^cZ
8dcYj^i 8dcYj^i
6eZgbVcZcianXdccZXiZY]VgYl^gZYedlZghje"
ean^hine^XVaan^chiVaaZYl^i]l^gZhgjcc^c\i]gdj\]
bdjciZY VcY hZXjgZY XdcYj^i# 6 Y^hXdccZXi^c\
bZVch! hjX] Vh V adX`^c\ hl^iX] hZZ [daadl^c\
Figure! bjhi WZ egdk^YZY id Vaadl i]Z bVX]^cZ
id WZ Y^hXdccZXiZY ^hdaViZY [gdb i]Z edlZg
hjeean l]Zc gZfj^gZY# I]^h ^chiVaaVi^dc bjhi WZ
eZg[dgbZYWnVcZaZXig^X^Vc^cVXXdgYVcXZl^i]Vaa
Veea^XVWaZZaZXig^XVaXdYZhVcYdgY^cVcXZh#
g9953zXF
I]^h bVX]^cZ ^h egZl^gZY id deZgViZ dc V ''%K
edlZghjeeanX^gXj^ii]Vi]VhVkZg^[^ZY\gdjcYVcY
bZZihi]Z[daadl^c\gZfj^gZbZcih/
