Spray Tip Selection Chart
309298J 51
Spray Tip Selection Chart
Part No.
Fan Width at
10 in. (250 mm)
in. (mm)
Orifice Size
in. (mm)
GG3107 2-4 (50-100) 0.007 (0.178)
GG3207 4-6 (100-150)
GG3307 6-8 (150-200)
GG3209 4-6 (100-150) 0.009 (0.229)
GG3309 6-8 (150-200)
GG3409 8-10 (200-250)
GG3211 4-6 (100-150) 0.011 (0.279)
GG3311 6-8 (150-200)
GG3411 8-10 (200-250)
GG3511 10-12 (250-300)
GG3611 12-14 (300-350)
GG3213 4-6 (100-150) 0.013 (0.330)
GG3313 6-8 (150-200)
GG3413 8-10 (200-250)
GG3513 10-12 (250-300)
GG3613 12-14 (300-350)
GG3215 4-6 (100-150) 0.015 (0.381)
GG3315 6-8 (150-200)
GG3415 8-10 (200-250)
GG3515 10-12 (250-300)
GG3615 12-14 (300-350)
GG3217 4-6 (100-150) 0.017 (0.432)
GG3317 6-8 (150-200)
GG3417 8-10 (200-250)
GG3517 10-12 (250-300)
GG3617 12-14 (300-350)
GG3319 6-8 (150-200) 0.019 (0.483)
GG3419 8-10 (200-250)
GG3519 10-12 (250-300)
GG3619 12-14 (300-350)
GG3719 14-16 (350-400)
GG3421 8-10 (200-250) 0.021 (0.533)
GG3521 10-12 (250-300)
GG3621 12-14 (300-350)
GG3721 14-16 (350-400)
GG3821 16-18 (400-450)
GG3423 8-10 (200-250) 0.023 (0.584)
GG3523 10-12 (250-300)
GG3623 12-14 (300-350)
GG3723 14-16 (350-400)
GG3823 16-18 (400-450)
GG3425 8-10 (200-250) 0.025 (0.635)
GG3525 10-12 (250-300)
GG3625 12-14 (300-350)
GG3725 14-16 (350-400)
GG3825 16-18 (400-450)
Part No.
Fan Width at
10 in. (250 mm)
in. (mm)
Orifice Size
in. (mm)
