Installation
10 309298J
Fig. 2. Typical Installation
Fig. 3. Optional Fiber Optic Connection
TI1741A
A
B C
E
F
J
K
M
N
G
NOTE:
* The turbine air supply (TA) must be electrically interlocked with the spray booth ventilation fans to prevent
the power supply from operating without ventilating fans on.
Non-Hazardous Area Hazardous Area
Y
W
P1
CYL
A2
KV2
TA
K
K
See *
above
K
X
KV1
L
L
Manifold Back View
KV
mA
85.0 KV
TI1715A
Q
T
NOTE:
** A maximum of two splices with a total of 108 ft (33 m) of cable can be used. For the strongest
light signals, use a minimum number of bulkhead splices. See Accessories on page 52.
Non-Hazardous Area Hazardous Area
H
U** R
P
S
V**
