65 (f – Graco Inc. 309475F User Manual
Page 7
Introduction
309475F
7
Fig. 2. Cutaway of Mechanical Fluid Pressure Regulator
Fig. 3. Cutaway of Pneumatic Fluid Pressure Regulator
TI1769A
Adjustment knob
Spring
Valve plunger
Adjustment knob
Fluid inlet
(from pump)
Adjustment knob
Fluid outlet
(to gun)
TI1769A
TI1774A
Fluid Outlet
(To gun)
Fluid Inlet
(From pump)
Diaphragm
Air Inlet
Valve plunger
