Installation
309475F
11
Fig. 6. High Pressure circulating system mechanical fluid regulator and back pressure regulator
Key
TI1765A
A
B
D
J
P
L
H
Air supply
Air to
gun
Fluid in
to gun
H
A
Air line filter
B
Bleed-type air shut-off valve
D
Pump air regulator
H
Fluid shut-off valve
J
Mechanical fluid regulator
L
Gun
P
Mechanical back pressure regulator
