List of Models
309475F 3
List of Models
Key to Model Designation
Part No. Series Model Type Maximum Fluid Inlet Pressure Regulated Pressure Range
233760
234266 B
B P60-VP DN7
P60-VP DN7 npt Pneumatic 5000 psi (36 MPa, 360 bar) 70-900 psi
(0.5-6 MPa, 5-60 bar)
233767
234264 B
B P200-VM
P200-VM npt Mechanical 5000 psi (36 MPa, 360 bar) 1300-3000 psi
(9-20 MPa, 90-200 bar)
233768
234265 B
B P200-VM
P200-VM npt Mechanical 5000 psi (36 MPa, 360 bar) 1300-4000 psi
(9-27 MPa, 90-270 bar)
233769
234270 B
B P150-VP DN7
P150-VP DN7 npt Pneumatic 5000 psi (36 MPa, 360 bar) 300-2000 psi
(2-15 MPa, 20-150 bar)
233770
234271 B
B P320-VP DN7
P320-VP DN7 npt Pneumatic 5000 psi (36 MPa, 360 bar) 600-4600 psi
(4-32 MPa, 40-320 bar)
233813
234259 B
B P250-VP
P250-VP npt Pneumatic 5000 psi (36 MPa, 360 bar) 600-3600 psi
(4-25 MPa, 40-250 bar)
233814
234260 B
B P100-VM
P100-VM npt Mechanical 2600 psi (18 MPa, 180 bar) 600-1500 psi
(4-10 MPa, 40-100 bar)
Back Pressure Regulators
Part No. Series Model Type
Maximum Permanent Supply
Pressure
Regulated Pressure Range
233771
234268 B
B P100-RM
P100-RM npt Mechanical,
back pressure 2500 psi (17 MPa, 170 bar) 600-1500 psi
(4-10 MPa, 40-100 bar)
233772
234269 B
B P200-RM
P200-RM npt Mechanical,
back pressure 3400 psi (23.5 MPa, 235 bar) 1300-3000 psi
(9-20 MPa, 90-200 bar)
Pressure regulation valve e.g. P60- R M DN7 npt
npt version
Valve Seat Orifice 7mm
Operating Mode P - pneumatic
M - mechanical
Action V - pressure regulation
R - back-pressure regulation
Regulation max 60 bar
