2-11
ITEM PART
#
COMPONENT
1
106-0215
Base Assembly, Quad—FM Common Electric (1F24)
*
106-0217
Base Assembly, Quad—FM Common Electric (31F2)
*
106-0218
Base Assembly, Quad—FM Common Electric (531F)
*
106-0220
Base Assembly, Quad—FM Common Electric (F246)
*
106-0214
Base Assembly, Triple—FM Common Electric (1F2)
*
106-0216
Base Assembly, Triple—FM Common Electric (31F)
*
106-0219
Base Assembly, Triple—FM Common Electric (F24)
*
106-0221
Base Assembly, Double—FM Common Electric (F2)
*
106-0222
Base Assembly, Double—FM Common Electric (1F)
2
200-0020
Shield, Filter Magic Pan CE
3
200-0074
Support, Rear Contactor Box
4
200-0075
Support, Front Contactor Box
5
200-0076
Divider, Cabinet Common Electric
6
200-0077
Brace, Rear Contactor Box
7
200-0078
Brace, Front Contactor Box Common Electric
8
200-0091
Brace (Rail), Top Quad Common Electric
*
200-0072
Brace (Rail), Top Triple Common Electric
*
200-0081SP
Brace (Rail), Top Double Common Electric
9
200-0092
Support, Rear Common Electric
10 200-0126
Brace,
Rear
Support
11
200-0138
Doorpost, Common Electric
12 200-0343
Brace,
Rear
Horizontal-Quad Common Electric
* 200-0085
Brace,
Rear
Horizontal-Triple Common Electric
* 200-0084
Brace,
Rear
Horizontal-Double Common Electric
13
201-0137
Upright, Rear Enclosure, Left, Common Electric
14
202-0137
Upright, Rear Enclosure, Right, Common Electric
15
806-8062SP
Filter Rail Assembly, Common Electric FM
16
826-1362
Nut, ¼ - 20 Hex (Pkg. of 10)
17
809-0191
Washer, ¼ Lock
18
826-1374
Screw, #10 - ½ Hex (Pkg. of 25)
19
809-0429
Bolt, ¼ - 20 x 2
20
826-1379
Screw, #10 x ½ Phillips (Pkg. of 10)
21 810-0665
Leveling
Nut
22 900-2861SP
Support,
Bottom Common Electric
23
900-4391SP
Brace, Cabinet Front
24
900-8582
Mount, Motor- Single FP Common Electric
25 910-2456SP
Side,
Cabinet—Stainless Steel Common Electric
*
900-2456SP
Side, Cabinet—Cold Rolled Steel Common Electric
26
826-1389
Screw, Hex Head— ¼-20 x ¾ (Pkg. of 10)
27
823-2827
Mount (Weld Assembly) Common Electric Single FP
28
900-8591
Bracket, Mount – Common Electric Single FP
* Not illustrated.
