F2
II. Hand-held Transmitter
Operating Voltage : 3.0 Vdc.
Power Source
: 2 "AAA" size batteries
Battery Life Expectancy
: more than 1 year
Range of Transmission
: at least 8m from the infrared sensor of the receiver module
Angle of Transmission
: 45° about normal
Medium of Transmission
: infrared transmission
The hand-held transmitter has an iconic LCD panel that displays the following information:
i) Iconic representation of current mode of operation
ii) Value of set/desired room temperature
iii) Iconic representation of current indoor fan speed
iv) Iconic representation of current vane position
v) Vane swing icon, appears if vane swing function has been activated.
vi) 12-hour format display of time of the day
vii) On/off timer settings, if timer function has been activated
viii) Sleep function icon, if sleep function has been activated
ix) Arrow icon to indicate the sequence of ON/OFF timer actions
x) “Signal transmitted” icon to indicate that transmission of command code to
receiver is being done.
The hand-held transmitter has one button for each of the following functions in manual
operation:
a) POWER ON/OFF button Toggles the air-con ON and OFF
b)
∧∧, the “Temperature
Increases the set temperature
Increment” button
c)
∨∨, the “Temperature
Decreases the set temperature
Decrement” button
d) MODE button
Toggles the mode of operation between AUTO,
COOL, DRY, FAN and HEAT (Heat Mode only
applicable on Heat Pump Unit).
e) FAN button
Toggles the fan speed between LOW, MEDIUM, HIGH
and AUTO.
f) SWING button
Causes the vane to be moved up and down continuously.
g) VANE button
Toggles vane position between ANGLE, DOWN,
MIDDLE and AUTO.
