Fedders R407C - Manual (Page 14)

E E E E
1 H 1 H
F F F F
C C C C
4 4 4 4
1 1 2 2
8 8 4 4
N N N N
Item 6 6 6 6
No. Description Service Part # G G G G
MODEL NUMBER
FEDDERS
LARGE SPLIT UNIT
OUTDOOR CONDENSER UNIT
(R407C)
-----REFRIGERANT ASSEMBLY(Cont')-----
16 Capillary Tube, 0.064" ID x 13" S0-02-C0002-N14 1 1 1 1
17 Condenser Assembly, Inner (14FPI) 35-24-08020-002 1 1 1 1
18 Condenser Assembly, Outer (14FPI) 35-24-08030-002 1 1 1 1
19 Plastic Coil Protection Mesh 37-24-01020-001 1 1 1 1
20 Compressor Kit '( with accessories) 50-16-0114N-001 1 1 -- --
Compressor Kit '( with accessories) 50-16-0115N-001 -- -- 1 1
24 Reversing Valve 37-03-08190-001 -- 1 -- 1
25 Crankcase Heater 35-11-00340-009 -- 1 -- --
Crankcase Heater 35-11-00340-010 -- -- -- 1
47 Check Valve 36-08-00580-001 -- 1 -- 1
51 Overload Protect (DB35-00011C) 35-05-00620-001 1 1 - -
70 Filter-Drier 37-01-05010-001 1 - 1 -
70 Filter-Drier 37-24-06110-001 - 1 - 1
NI Strainer 88-60-00220-007 1 1 1 1
-----ELECTRICAL ASSEMBLY-----
26 Terminal Block, 3 Pole 35-03-00570-001 1 -- 1 --
Terminal Block, 5 Pole 35-03-00580-001 -- 1 -- 1
27 Control Box 35-24-05040-001 1 1 1 1
28 Fan Motor Capacitor, 3uF 16-05-00750-002 1 1 1 1
29 Compressor Capacitor, 40uF/440V 16-05-00730-132 1 1 1 1
30 Strap, Capacitor 35-05-00240-001 1 1 1 1
31 Start Assist 16-06-03480-001 1 1 1 1
32 Strain Relief (Multi Usage Type) 35-03-25060-001 2 2 2 2
33 Thermostat-Bimetal 11-23-03950-001 -- 1 -- 1
B9
