20 SPARC Enterprise T5140 and T5240 Servers Administration Guide • July 2009
4. Install the volume with the Solaris OS using any supported method.
The hardware RAID volume c1t0d0 appears as a disk to the Solaris installation
program.
Note – The logical device names might appear differently on your system,
depending on the number and type of add-on disk controllers installed.
Related Information
■ “Disk Slot Numbers” on page 35
■ “Create a Hardware Mirrored Volume” on page 15
■ “Configure a Hardware RAID Volume for the Solaris OS” on page 22
▼ Create a Hardware Striped Volume
1. Verify which hard drive corresponds with which logical device name and
physical device name.
See “Disk Slot Numbers” on page 35 .
To verify the current RAID configuration, type:
The preceding example indicates that no RAID volume exists.
# raidctl
Controller: 1
Disk: 0.0.0
Disk: 0.1.0
Disk: 0.2.0
Disk: 0.3.0
Disk: 0.4.0
Disk: 0.5.0
Disk: 0.6.0
Disk: 0.7.0
