APPENDEX
AP-2
1. PLOTTER SETUP
2. UNIT SETUP
4. DATA TRANSFER
5. DATA4 I/O SETUP
9. SYSTEM SETTINGS
Unit of Depth (m, ft, fm)
Unit of TEMP ( C, F)
3. DATA1, 3 OUTPUT SETUP
Unit of Altitude (m, ft)
Unit of Distance (NM, km, sm)
Data (Out, COM, DGPS)
Data FMT (V1.5, V2.0, IEC)
Talker ID (GP, LC, DE)
Data4. Level (RS232C, RS422)
Output Data
Talker ID (GP, LC, DE)
Output Data
AAM: 00, APA: 00, APB: 04, BOD: 00,
BWR: 00, BWW: 00, GGA: 00, GLL: 01,
RMB: 01, RMC: 00, VTG: 01, WCV:00,
VDR: 00, WPL: 00, XTE: 00, ZDA: 01,
GNS: 00, GBS: 01, Rnn: 00, RTE: 00
AAM: 00, APA: 00, APB: 04, BOD: 00,
BWR: 00, BWW: 00, GGA: 00, GLL: 01,
RMB: 01, RMC: 00, VTG: 01, WCV:00,
VDR: 00, WPL: 00, XTE: 00, ZDA: 01,
GNS: 00, GBS: 01, Rnn: 00, RTE: 00
Data FMT (V1.5, V2.0, IEC)
Bearing REF (True, MAG)
MAG Variation (AUTO, MAN)
(07˚W) (00˚E)
User defined
#1 RNG
#2 SOG
#3 BRG
#4 COG
SOG, COG, RNG, BRG,
WAT TEMP, WAT DEPTH, XTE,
dCOG, AVR SOG, AVR COG, TTG,
ETA, TRIP, TRIP TIME, ROUTE
DIST, ROUTE TTG, ROUTE. ETA,
ALT, VTD, DRIFT, SET, STW, HDG
Memory Apportion (TRK: 1000/2000 Pt)
Calculation (RL, GC)
2
ALL (Stop, Start)
1
