5.3.8 Map Descriptor Example 6: Run-Stop PLC:
This Map Descriptor enables the Driver to give access to the Client to change the Server’s Operating Mode. See Appendix A for stored values corresponding to
PLC modes.
Map_Descriptor_Name ,Data_Array_Name ,Data_Array_Offset ,Function ,Node_Name ,Length ,Command_Name ,Unit_Number
SRV_RUN_ST ,DA_RUN_ST ,0 ,SERVER ,PLC1 ,1 ,RUN-STOP ,0
5.3.9 Map Descriptor Example 7: CPU Status:
This Map Descriptor enables the Driver to respond to clients requesting CPU status. See Appendix Afor further information.
Map_Descriptor_Name ,Data_Array_Name ,Data_Array_Offset ,Function ,Node_Name ,Length ,Command_Name ,Unit_Number
SRV_STATUS ,DA_STATUS ,0 ,SERVER ,PLC1 ,67 ,CPU UNIT STATUS READ ,0
