background image

FS-8704-16 Omron FINS Manual Page 18 of 38

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: [email protected]

5.2

Server Side Node Descriptors

Section Title
Nodes
Column Title

Function

Legal Values

Node_Name

Provide name for node

Up

to

32

alphanumeric

characters

Node_ID

Virtual Node number of FINS server.

1-126

Protocol

Specify protocol used

Fins, omn_fins or fins_udp

Server_Hold_Timeout*

Specifies time FieldServer will reserve server side
connection while waiting for the Client side to
update data in Data_Array (if necessary)

>1.0s

Net_Number

Provide the network number of FINS Server
network

1-255

Example

5.3

Server Side Map Descriptors

5.3.1 FieldServer Specific Map Descriptor Parameters

Column Title

Function

Legal Values

Map_Descriptor_Name

Name of this Map Descriptor

Up to 32 alphanumeric characters

Data_Array_Name

Name of Data Array where data is to be
stored in the FieldServer

One of the Data Array names from
“Data Array” section above

Data_Array_Offset

Starting location in Data Array

0 to maximum specified in “Data
Array” section above

Function

Function of Server Map Descriptor

Server

// Server Side Nodes

Nodes

Node_Name

,Node_ID

,Protocol

,Net_Numer

PLC 1

,1

,Modbus_RTU,

,1
