FS-8704-16 Omron FINS Manual Page 11 of 38

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: [email protected]

4.4

Client Side Node Descriptors

Section Title
Nodes
Column Title

Function

Legal Values

Node_Name

Provide name for node

Up

to

32

alphanumeric

characters

IP_Address

Provide IP Address of PLC

Eg. 192.168.1.105

Node_ID

Node number set at PLC
The node number should correspond to the last byte
of the IP address. Eg. 105 corresponds to the
example IP address above.

1-126

Protocol

Specify protocol used

Fins, omn_fins or fins_udp

Adapter

Specify which port the device is connected to the
FieldServer

N1, N23

*Net_Number

Provide the network number of PLC

1-255

Example

// Client Side Nodes

Nodes

Node_Name

,IP_Address

,Node_ID

,Protocol

,Adapter

,Net_Number

PLC 1

,192.168.1.5

,1

,Fins

,N1

,1


3

Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for

details of the ports available on specific hardware.
