4.5.9 Map Descriptor Example 6: Run-Stop PLC:
Defining this Map Descriptor Driver can change the PLC mode to STOP (Program), MONITOR or RUN mode. The Driver issues a change mode command to the
PLC whenever the value at the declared offset is updated.
Map_Descriptor_Name ,Data_Array_Name ,Data_Array_Offset ,Function ,Node_name ,Length ,Command_Name ,Unit_Number
CMD_RUN_ST ,DA_RUN_ST ,0 ,WRBX ,PLC1 ,1 ,RUN-STOP ,0s
The Driver will change PLC modes depending upon the value poked by the upstream device at offset (0 in this case). See section Appendix A for values
corresponding to PLC modes.
4.5.10 Map Descriptor Example 7: Read CPU Status:
Defining this Map Descriptor Driver reads the CPU status and stores it in the Data Array DA_STATUS.
Map_Descriptor_Name ,Data_Array_Name ,Data_Array_Offset ,Function ,Node_name ,Length ,Command_Name ,Unit_Number
CMD_STATUS ,DA_STATUS ,0 ,REBC ,PLC1 ,67 ,CPU UNIT STATUS READ ,0s
The Driver stores the status information in the named Data Array at consecutive locations starting with Data_Array_Offset.
See Appendix A for further information.
